Fluke 190-504-III Offers

Accurate and versatile, this portable oscilloscope provides a fast sampling rate of up to 5 GS/s, a 200 ps resolution, and deep memory of 10,000 samples per channel. Perform timing or amplitude-related measurements on three phases or three-axis control systems, or compare and contrast multiple test points in a circuit under test

- Up to four independent floating isolated inputs, up to 1000 V

- Up to 5 GS/s real time sampling (depending on model and channels used)

- Deep memory: 10,000 points per trace waveform capture (scope mode)

- CAT III 1000 V/CAT IV 600 V safety rated instrument for industrial environments

- Up to seven hours of battery operation using BP291

- Large, bright color display is easy to view in nearly any environment

- Easy to store and view historical data and transfer to a PC via USB or Wifi

- Convenient battery access door for quick battery swaps in the field

- IP51 rating, dust and drip-proof

- Connect-and-View triggering for intelligent, automatic triggering on fast, slow and even complex signals

- Frequency spectrum using FFT-analysis

- Automatic capture and REPLAY of 100 screens

- ScopeRecord mode gives 30,000 points per input channel for low frequency signal analysis

- TrendPlot Paperless Recorder mode with deep memory for longterm automatic measurements

- 5000 count DMM included in the 2-channel models



Applications

- Microelectronics

- Troubleshooting



Measure from mV to kV safely



Independently isolated inputs allow you to make measurements in mixed circuits having different ground references reducing the risk of accidental short circuits. Conventional bench oscilloscopes without special differential probes and isolation transformers can only reference measurements to line power earth ground. ScopeMeter 190 Series III test tools are engineered to cover a wide application range from mV to kV, so you’re ready for anything from microelectronics to heavy duty higher voltage electrical applications. 190 Series III 60 MHz and 100 MHz configurations include VPS421 100:1 probes for higher voltage applications, while the 200 MHz and 500 MHz configurations include VPS410-II 10:1 probes suitable for both microelectronics and higher voltage applications.



IP-51 rated for harsh environments



Rugged and shock-proof, ScopeMeter Test Tools are built for dirty, hazardous environments. With its sealed case, it can endure dust, drips, humidity and airborne pollutants. Every time you reach for ScopeMeter Test Tool you can be confident it will work reliably wherever your work takes you.



USB and Wi-Fi connectivity



The Fluke 190 Series III offers two USB ports, electrically isolated from measurement input circuits allowing you to quickly and easily transfer data to a PC, archive and share waveforms with OEMs, colleagues and support staff, or store waveforms, screen captures and instrument setups onto USB memory devices for later use. Easily transfer saved files via USB stick, direct connection via the USB interface or optional Wi-Fi connectivity. These files can be used for further data handling or in FlukeView-2 Software to study waveforms in greater detail.



Connect-and-View triggering



Connect-and-View triggering provides an instant, stable display without the need for adjusting settings. If you’ve used other scopes, you know how tricky triggering can be. If settings are incorrect, results can be unstable or incorrect. Connect-and-View automatically sets up correct triggering by recognizing signal patterns. Without touching a button, you get a stable, reliable and repeatable display of virtually any signal including motor drive and control signals. It’s especially fast and convenient when you’re measuring a number of test points in rapid succession.



Built-in digital multimeter



Conveniently switch from waveform analysis to precise multimeter measurements using the built in 5000 count digital multimeter on two channel 190 Series III models. Measurement functions include Vdc, Vac, Vac+dc, resistance, continuity and diode test. Measure current and temperature using suitable shunt, probe or adapter with wide range of scaling factors.



TrendPlot paperless recorder— records up to 11 days to help you find intermittent faults



The toughest faults to find are those that happen only once in a while. These intermittent events can be caused by bad connections, dust, dirt, corrosion, or simply broken wiring or connectors. Line outages, dips, swells and interruptions, or the starting and stopping of a motor can also cause a machine to stop. You may not be around when it happens, but the 190 Series III ScopeMeter Test Tool will be.

- Plot minimum and maximum peak values and average over time

- Plot any combination of up to four readings including voltages, amps, temperature, frequency and phase for all inputs, all with time and date stamp to pinpoint faults

Precision laser alignment made easy
The rugged Fluke 831 has an intuitive guided user interface that enables quick and complete shaft alignment without advanced training or complicated programs. And while it’s easy to use, laser alignment with the Fluke 831 is powerful enough for the skilled technician. You can cover more of your machines with all the functionality needed on the plant floor, from thermal growth to user defined tolerances and more.

Reduce costs by avoiding downtime
Misalignment causes at least half of all damage to rotating machinery, studies show. Instead of fixing the problem, teams often just treat the symptoms of misalignment and replace bearings, couplings, and seals because they think alignment takes too long.
Contrary to expectations, laser alignment can be fast and easy. So, every machine that is repaired and overhauled should be aligned – not just a few. Teams that embrace laser alignment can save thousands of dollars per year by avoiding downtime and energy waste and reducing the number of bearings and seals they have to replace.

Key features
• Fast, easy, and precise alignment that adapts to your needs.
• Rugged build and the highest-in-class IP rating.
• Single-laser technology for the fastest, most accurate laser alignment.
• Cloud connection enables real-time collaboration.
• Use up to 8 measurement points to achieve precision alignment on vertical machines.

From the control room to the factory floor, the Fluke 80 Series digital multimeter has earned a reputation as the digital multimeter that industrial technicians trust. When productivity suffers, the Fluke 80 Series provides the accuracy and advanced troubleshooting capabilities you need to solve problems fast.



Use the low pass filter function to accurately measure voltage and frequency on electrically noisy equipment such as variable speed motor drives. Use the peak capture function to detect occasional faults and switch as fast as 250 microseconds (µs).



And work with confidence. The Input Alert function provides an audio alert against misuse of the input plug. The Fluke 80 Series multimeters have been tested separately for use in CAT IV 600 V/CAT III 1000 V environments. The Series can withstand impulses in excess of 8000 V and reduce the risks associated with surges and surges.



At Fluke, our ideas come straight from the workplace. We work with users like you to build test kits that do the job you want them to do for as long as you need them—and give you full value. We design and manufacture the Fluke 80 Series multimeters in the U.S.A. The 80 Series is backed by a limited lifetime warranty. And we back it with a limited lifetime warranty so you can work smarter, faster, and safer.

• 3 phase indication

• Indication of phase rotation

• Clear LCD display

• No battery required
