Fluke 124B Offers



Compact and rugged, this oscilloscope is ideal for industrial electrical and electro-mechanical equipment troubleshooting and maintenance applications. Features innovative functions that help technicians troubleshoot faster for quicker results and to keep their systems running smoothly. Additionally, triggering displays waveforms without having to adjust amplitude, timebase, and trigger settings.



Features

- Key measurements: Voltage and power waveforms

- Automatically capture, view and analyze complex waveforms: Fluke Connect and View™ triggering automatically displays waveforms without having to adjust amplitude, timebase and trigger settings, while Intellaset™ technology analyzes the signal and automatically displays critical numerical readings, making troubleshooting faster than ever

- View data locally on the instrument, or via Fluke Connect mobile app

- Dual-input digital oscilloscope and multimeter

- 40 MHz oscilloscope bandwidth

- Two 5000-count true-rms digital multimeters

- Connect-and-View trigger simplicity for hands-off operation

- IntellaSet technology automatically and intelligently adjusts numerical readout based on the measured signal

- Dual-input waveform and meter reading recorder for trending data over extended periods

- Recorder Event Detect captures elusive intermittent signals on repetitive waveforms up to 4 kHz

- Shielded test leads for oscilloscope, resistance and continuity measurements

- Resistance, continuity, diode and capacitance meter measurements

- Power measurements (W, VA, VAR, PF, DPF, Hz)

- Save or recall data and instrument setups

- Store instrument setups defined by a test sequence for routine maintenance or most often used test procedures

- External optically isolated USB interface to transfer, archive and analyze scope or meter data

- Optional WiFi adapter connected to internal USB port to wirelessly transfer information to the PC, laptop or Fluke Connect mobile app

- Rugged design to withstand 3 g Vibration, 30 g shock, and rated IP51 according to EN/IEC60529

- Highest safety rating in the industry: safety rated for CAT IV 600 V



Connect-and-View triggering for an instant, stable display



Oscilloscope users know how difficult triggering can be. Using the wrong settings can lead to unstable waveform captures, and sometimes the wrong measurement data. This instrument's unique Connect-andView triggering technology recognizes signal patterns and automatically sets up the correct triggering to provide a stable, reliable, and repeatable display. Connect-and-View triggering is designed to work with virtually any signal, including motor drives and control signals - without adjusting parameters, or even touching a button. Signal changes are instantly recognized and settings are automatically adjusted, providing a stable display even when measuring multiple test points in quick succession.



IntellaSet/AutoReading



The Auto Readings function with Fluke IntellaSet technology uses proprietary algorithms to intelligently analyze the measured waveform and automatically displays the most appropriate numerical measurements on the screen, so you can get the data you need easier than ever before. As an example, when the measured waveform is a line voltage signal, the Vrms and Hz readings are automatically displayed, whereas if the measured waveform is a square wave, the Vpeak-peak, and Hz readings are automatically displayed. Using IntellaSet technology in conjunction with Connect-and-View automatic triggering you can be sure you're seeing not only the correct waveform but the appropriate numerical reading as well. All without touching a button.



Industrial equipment needs a reliable power supply to operate properly, use the dual input to obtain key power measurements



For single-phase or 3-phase balanced systems, the dual inputs of the Industrial ScopeMeter 120B Series can measure AC+DC RMS voltage on channel A and AC+DC RMS current on channel B. This oscilloscope can then calculate; frequency, phase angle, active power (kW), reactive power (VA or var), power factor (PF), or displacement power factor (DPF) and can also calculate the power values for a 3-phase system where all phases have equal voltage and currents. This applies to both balanced systems and resistive loads.



One test lead to measure multiple electrical parameters



High-frequency waveform, meter, capacitance, and resistance measurements as well as continuity checks are all covered by a single set of shielded test leads. No time is wasted finding or swapping leads.



Fluke Connect mobile app compatibility



Automated industrial machinery is harder than ever to troubleshoot. It's not enough to just know where you have to test, you also have to know what to look for and that can be hard without baseline measurement data or access to subject matter experts. This Fluke Connect Assets wireless system of software and wireless test tools enables technicians to reduce maintenance costs and increase uptime with accurate equipment records and maintenance data that is easy to interpret, and share. Compare and contrast test point measurement data and trends so you can better understand signal characteristics and changes over time. And, by storing maintenance data on the Fluke Cloud you can enable team members to access it from wherever and whenever they need to so you can get advice or approvals in the field and get your systems up and running faster than ever before.



Use the comprehensive recorder modes to help find intermittent faults with ease



The toughest faults to find are those that happen only once in a while-intermittent event. They can be caused by bad connections, dust, dirt, corrosion, or simply broken wiring or connectors. Other factors, like line outages and sags or the starting and stopping of a motor, can also cause intermittent events resulting in equipment shutdowns. When these events happen, you may not be around to see them. But, your Fluke ScopeMeter Test Tool will. You can either plot the minimum and maximum peak measurement values or record the waveform trace. And, with expandable micro SD memory, recording sessions can be done for up to 14 days. This recorder is even more powerful with the addition of Recorder Event Detect, which makes detecting and logging intermittent faults easier than ever. Just set a threshold on a meter reading or scope trace and deviations are tagged as unique events. You no longer need to search through masses of data to pinpoint faults, and can quickly step from one tagged event to the next, while still having access to the full data

Now there is one intrinsically safe digital multimeter (DMM) you can use in IIC (gas), in Zones 1 and 2, and IIIC (dust), Zones 21 and 22. Whether you work in an oil, chemical, or pharmaceutical environment , all the test and troubleshooting capabilities you need are in the most robust and intrinsically secure (IS) Fluke DMM ever made. The Fluke 28 II Ex is also water, dust and drop resistant. You will be equipped to solve all problems, inside and outside the danger zone, without compromising on compliance or measurement performance.

Save time with precise infrared levels and analysis

Whether you're on the roof checking heating, ventilation and air conditioning, deep in the factory checking motors, or if you've locked down the electrical panels, you rely on a tool that has the power and features to do the job quickly.



The Fluke TiS20+ and TiS20+ MAX handheld thermal cameras put the power of thermal imaging at your fingertips. Designed to make your job faster and easier, this thermal imager is the perfect tool for:

- Commercial electrician

- Heating, ventilation, air conditioning and refrigeration technician

- Maintenance technician



Get context with a combination of visual light and infrared images

In thermography, context is important. Let Fluke IR-Fusion™ make your job easier by using a thermal image superimposed on a visual light image to provide a complete picture of where an issue is a problem before it actually becomes a problem. Just slide your finger across the screen to adjust the infrared level. Whether you're experiencing an uneven load on your switchgear or checking your ventilation system, the Fluke TiS20+ helps you quickly detect issues.



You work hard all day, your tools too

You must not let your thermal imager be damaged by the environment. You can sleep well at night knowing that your camera will stand up to whatever the day throws at it.

- 2 meter high drop test

- Waterproof (IP54)

- Dustproof (IP54)



Stop sorting, start analyzing with Fluke Connect Asset Tagging

Avoid long hours on the computer setting up your thermal images, let Asset Tagging do all the work for you. No more dragging and dropping or renaming files in the office, just scan the QR code on your assets, take thermal images and they are automatically sorted by assets. Start spending your time analyzing images and creating reports instead of sorting files one by one.



Longest battery life in a Fluke thermal camera

The TiS20+ and TiS20+ MAX work non-stop, with a battery life of over 5 hours of continuous use making it the longest battery life in a Fluke thermal camera. Save battery power for multiple inspection points with sleep mode. Just press the power button once and you are ready to go.

When it's not just infrared.



Introducing Fluke infrared cameras, the first with full radiometry technology – the RSE series. Packed with advanced features and plug-in software for MATLAB® and LabVIEW® , these tools are ideal for continuous streaming and analysis of infrared data.



Designed for your research, science and engineering needs, enhance your testing and quality assurance procedures by attaching the RSE600 to your workstation. Continuously stream up to 60 frames per second of data directly to your computer to monitor minute temperature differences, as well as analyze remote video frame-by-frame from the SmartView® desktop software . Get an even more perfect screen with add-on lenses to target different applications (analyzing from a distance, or getting detailed close-ups).



Don't just look at the heat. Stream, measure and analyze its power as well.



With plug-ins for MATLAB® and LabVIEW® , the RSE Infrared Camera is perfect for testing and development. Looking for more robust software to monitor and archive processing manufacturing data 24/7? We recommend the ThermoView® series from Fluke Process Instruments. Check out a quick comparison
