The Fluke 1760 Three-Phase Power Quality Recorder complies strictly with IEC 61000-4-30 Class-A, for advanced power quality analysis and consistent conformity testing. Designed for the analysis of utility and industrial power distribution systems, in medium and low voltage networks, these power quality monitors give customers the flexibility to customize threshold selection, algorithms and measurements. The Fluke 1760 power recorder records the most thorough detail for user-selected parameters.



Usage



Detailed fault analysis – Performs high-speed transient analysis and finds root causes of equipment malfunctions for later mitigation of malfunctions and predictive maintenance. The fast transient option, with a measuring range of 6,000 V, makes it possible to record very short impulses such as lightning strikes.



Class-A Quality of Service Compliance – Validates the quality of incoming power at the service gateway. Thanks to Class A conformance, the Fluke 1760 allows unquestioned verification.



Correlation of events at multiple locations – Using GPS time synchronization, users can quickly detect where a fault first occurred, both inside and outside the facility.



Galvanic separation and DC coupling – Allows complete measurement of dissimilar power systems. For example, troubleshooting a UPS system by simultaneously recording battery voltage and power output.



Power quality and power load monitoring – Assess baseline power quality to validate compatibility with critical systems prior to installation and verify electrical system capacity before increasing loads.

Sturdy Flukes. Reliable Flukes. Flukes are accurate.



True-rms measurements and optimized ergonomics make the 320 Series Clamp Meters the best general troubleshooting tool for commercial and residential electricians. The 323, 324 and 325 series are designed to check for the presence of load current, AC voltage and continuity of circuits, switches, fuses and contacts. These small, sturdy clamp gauges are ideally suited for current measurements up to 400 A in tight cable enclosures. The Fluke 325 also offers DC current and frequency measurements.

Portable true-rms meter for commercial applications. The Fluke 117 is the ideal gauge for demand settings such as trade center buildings, hospitals, schools. The Fluke 117 includes integrated non-contact voltage detection to help get jobs done faster.



See also the Fluke 114 Electrical Multimeter, Fluke 115 Multimeter, and Fluke 116 HVAC Multimeter with Temperature and Microamp.

When it's not just infrared.



Introducing Fluke infrared cameras, the first with full radiometry technology – the RSE series. Packed with advanced features and plug-in software for MATLAB® and LabVIEW® , these tools are ideal for continuous streaming and analysis of infrared data.



Designed for your research, science and engineering needs, enhance your testing and quality assurance procedures by attaching the RSE600 to your workstation. Continuously stream up to 60 frames per second of data directly to your computer to monitor minute temperature differences, as well as analyze remote video frame-by-frame from the SmartView® desktop software . Get an even more perfect screen with add-on lenses to target different applications (analyzing from a distance, or getting detailed close-ups).



Don't just look at the heat. Stream, measure and analyze its power as well.



With plug-ins for MATLAB® and LabVIEW® , the RSE Infrared Camera is perfect for testing and development. Looking for more robust software to monitor and archive processing manufacturing data 24/7? We recommend the ThermoView® series from Fluke Process Instruments. Check out a quick comparison
