Fluke 190-204-III-S Offers

Accurate and versatile, this portable oscilloscope provides a fast sampling rate of up to 5 GS/s, a 200 ps resolution, and deep memory of 10,000 samples per channel. Perform timing or amplitude-related measurements on three phases or three-axis control systems, or compare and contrast multiple test points in a circuit under test.

- Up to four independent floating isolated inputs, up to 1000 V

- Up to 5 GS/s real time sampling (depending on model and channels used)

- Deep memory: 10,000 points per trace waveform capture (scope mode)

- CAT III 1000 V/CAT IV 600 V safety rated instrument for industrial environments

- Up to seven hours of battery operation using BP291

- Large, bright color display is easy to view in nearly any environment

- Easy to store and view historical data and transfer to a PC via USB or Wifi

- Convenient battery access door for quick battery swaps in the field

- IP51 rating, dust and drip-proof

- Connect-and-View triggering for intelligent, automatic triggering on fast, slow and even complex signals

- Frequency spectrum using FFT-analysis

- Automatic capture and REPLAY of 100 screens

- ScopeRecord mode gives 30,000 points per input channel for low frequency signal analysis

- TrendPlot Paperless Recorder mode with deep memory for longterm automatic measurements

- 5000 count DMM included in the 2-channel models



Applications

- Microelectronics

- Troubleshooting



Measure from mV to kV safely



Independently isolated inputs allow you to make measurements in mixed circuits having different ground references reducing the risk of accidental short circuits. Conventional bench oscilloscopes without special differential probes and isolation transformers can only reference measurements to line power earth ground. ScopeMeter 190 Series III test tools are engineered to cover a wide application range from mV to kV, so you’re ready for anything from microelectronics to heavy duty higher voltage electrical applications. 190 Series III 60 MHz and 100 MHz configurations include VPS421 100:1 probes for higher voltage applications, while the 200 MHz and 500 MHz configurations include VPS410-II 10:1 probes suitable for both microelectronics and higher voltage applications.



IP-51 rated for harsh environments



Rugged and shock-proof, ScopeMeter Test Tools are built for dirty, hazardous environments. With its sealed case, it can endure dust, drips, humidity and airborne pollutants. Every time you reach for ScopeMeter Test Tool you can be confident it will work reliably wherever your work takes you.



USB and Wi-Fi connectivity



The Fluke 190 Series III offers two USB ports, electrically isolated from measurement input circuits allowing you to quickly and easily transfer data to a PC, archive and share waveforms with OEMs, colleagues and support staff, or store waveforms, screen captures and instrument setups onto USB memory devices for later use. Easily transfer saved files via USB stick, direct connection via the USB interface or optional Wi-Fi connectivity. These files can be used for further data handling or in FlukeView-2 Software to study waveforms in greater detail.



Connect-and-View triggering



Connect-and-View triggering provides an instant, stable display without the need for adjusting settings. If you’ve used other scopes, you know how tricky triggering can be. If settings are incorrect, results can be unstable or incorrect. Connect-and-View automatically sets up correct triggering by recognizing signal patterns. Without touching a button, you get a stable, reliable and repeatable display of virtually any signal including motor drive and control signals. It’s especially fast and convenient when you’re measuring a number of test points in rapid succession.



Built-in digital multimeter



Conveniently switch from waveform analysis to precise multimeter measurements using the built in 5000 count digital multimeter on two channel 190 Series III models. Measurement functions include Vdc, Vac, Vac+dc, resistance, continuity and diode test. Measure current and temperature using suitable shunt, probe or adapter with wide range of scaling factors.



TrendPlot paperless recorder— records up to 11 days to help you find intermittent faults



The toughest faults to find are those that happen only once in a while. These intermittent events can be caused by bad connections, dust, dirt, corrosion, or simply broken wiring or connectors. Line outages, dips, swells and interruptions, or the starting and stopping of a motor can also cause a machine to stop. You may not be around when it happens, but the 190 Series III ScopeMeter Test Tool will be.

- Plot minimum and maximum peak values and average over time

- Plot any combination of up to four readings including voltages, amps, temperature, frequency and phase for all inputs, all with time and date stamp to pinpoint faults

Portable multi-function calibrator simplifies calibration work



Whether you're calibrating instruments, troubleshooting a problem, or running routine maintenance, the Fluke 754 with HART® communication can help you get the job done faster. It does many different tasks quickly and it's the only process calibrator you need to carry. This rugged, reliable, integrated communicating calibrator is ideal for calibrating, maintaining, and troubleshooting HART smart transmitters and other instrumentation.



Measurement and source capabilities:

- AC/DC voltage

- mA loop w/ 24V loop power

- Pressure

- Thermocouples & RTDs

- Frequency

- Resistance



Enhanced process calibrator operation



With the bright white dual display, you’ll be able to read both sourced and measured parameters simultaneously. The rechargeable Li-Ion battery offers up to 10 hours uninterrupted usage allowing you to complete one task after another without needing to stop, and also includes direct AC power capabilities if needed. Finally, communicate with HART smart digital transmitters directly through the mA measurement jacks for seamless calibration with fewer connections.



Do more, with less

The 754 does the work of several tools. It sources, simulates and measures pressure, temperature, and electrical signals with one rugged, hand-held device. The powerful built-in HART interface can perform nearly all day-to-day tasks you now perform with a separate digital communicator. It can handle fast-pulsed RTD transmitters and PLCs, with pulses as short as 1 ms. The 754 also measures/sources pressure using any of the Fluke 750P Series Pressure Modules as a reference and boasts many additional features like:

- Custom auto-step and ramping

- Custom units

- User-entered values during test

- One-point and two-point switch testing

- Square root DP flow testing

- Programmable measurement delay



Download procedures, lists, and instructions



The 754 is a power multifunction documenting calibrator that you can use to download procedures, lists, and instructions created with software, or upload data for printing, archiving, and analysis. The tool can hold up to a full week of downloaded procedures and calibration results and offers compatibility with many asset management software. Users can also create and run automated as-found or as-left procedures to satisfy quality programs or regulations, and records and documents results.



For documentation, the 754 automates calibration procedures and captures your data. And, of course, it helps you meet rigorous standards like ISO 9000, FDA, EPA, and OSHA regulations. Plus, the graphical screen, Li-Ion battery for longer life, USB port, and accessories help you work smarter and faster.



To create a seamless/paperless calibration management system consider adding Fluke DPCTrack2 Calibration Management software.

Available in a range of sizes, this digital caliper is coolant, water and dust proof to IP67 level. It has a large LCD display, fast response speed, dual readout (mm/inch) and can be used for inside, outside, depth and step measuring. Also enables absolute and relative reading.



Extra batteries available - Order Code PAN9042505E 3V Lithium Metal cell

Equipped with an array of microphones for a wider field of view, the Fluke ii900 Sonic Industrial Imager enables maintenance teams to quickly and accurately locate air, gas and vacuum leaks in compressed air systems; even in a noisy environment. Designed especially for noisy production lines, SoundSight™ Technology is easy to learn and apply. The 7” LCD touch screen displays SoundMap™ on a visual image for quick identification of leak locations. A clear and intuitive interface allows technicians to isolate sound frequencies from leaks to filter out loud background noise. In a few hours, the team can inspect the entire plant - even in busy operations. For the first time, You can quickly and easily identify the air leak repairs needed to ensure efficient operation and reduce utility bills. Images can be saved and exported for reporting purposes. Never again take air leaks for granted.
