Type of Luminaire : Smart Street Light
Set Model No : NSP10460LR
Type of Light Source : LED
Power Input : 100W
System Lumen Output : 18000 lm
System Efficacy : 180 lm/W
Lifetime : 50000H(L70)
CRI : 70
Dimming : non-Dimmable
Glare Cut Angle : 30deg.
Beam Angle : 120deg.
IP Rating : 66
Ambient Temperature : 5 - 40°C
Dimensions : 340mmx703mmx132mm
Body : ADC & Aluminium Extrution

Type of Luminaire : Standard Floodlight (Pro) A Series
Set Model No : NYS12517LD2031
Type of Light Source : LED
Power Input : 442W
System Lumen Output : 63200 lm
Power Voltage : 200-242V
Lifetime : 40000H(L70)
CCT : 5000K
CRI : 70
Input Frequency : 50/60Hz
Dimming : non-Dimmable
Glare Cut Angle : 77deg.
Beam Angle : 27deg.
IP Rating : 65
Ambient Temperature : -20 - 35°C
Dimensions : 487mmx534mmx500mm
Body : ADC

This Acti9 iK60N product is a low voltage miniature circuit breaker (MCB). It is a 1P circuit breaker with 1 protected pole and 40A In rated current and C tripping curve. The rated short circuit breaking capacity goes up to 6000A at 230VAC conforming to EN/IEC 60898-1 standard and at conforming to standard. This product is compliant with EN/IEC 60898-1 standard. This miniature circuit breaker protects circuit against short circuit and overload current. It has a double clip for dismounting with comb busbar in place. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 230VAC. The Ui rated insulation voltage is 440VAC. The Uimp rated impulse withstand voltage is 4kV. The operating frequency is 50Hz or 60Hz. It can be mounted on DIN rail for modular installation. Its width is 2 pitches of 9mm. The product colour is white (RAL9003). The dimensions are (W) 18mm x (H) 85mm x (D) 78.5mm. The weight is 100g. It has an IP20 degree of protection. It becomes IP40 once in modular enclosure according to IEC/EN 60529 standard. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 85°C.

M12 PAL-0
• 700 Lumens of TRUEVIEW™ High Definition Output
• Up to 24 Hours of Run-time w/ 4.0Ah Battery (High: 8 Hrs, Low: 24 Hrs)
• 2.1 AMP USB Output for Device Charging
