CNMG Turning Inserts

80° Rhombic Insert

Insert Grade QX5030
(ISO P20-P40 M20-M30) CVD Coated. - Medium / rough turning and intermediate cutting of steel / stainless steel. Combination of toughest substrate and alumina coating (MT-TiCN + TiC + AL2O3 + TiN) having superior chipping resistance provide wide coverage.

Chip Breaker: NM6. Application: Med Cut.

These carbide burrs are designed for cylindrical end cutting of low feed, high speed materials. Available in a variety of sizes with varying cut capabilities.

Features and Benefits
• Manufactured from durable carbide for tool longevity
• Rapid cut (Cut 3) burrs are suited for use on softer non-ferrous and plastic materials
• Chipbreaker (Cut 9) burrs are suited for use on cast iron, carbon steel, alloy steel 50RC and 60RC
• Suitable for deburring and polishing of cast iron, cast steel, carbon steel, alloy steel and stainless steel up to HRC65 hardness
• Ideal for light stock removal at high rpms

Typical Applications
• Deburring

Notes
• Not suitable for milling large amounts of material
• Always ensure that at least 70% of the shank length is clamped by the collet or chuck of the tool being used
• Always ensure that the tool is rated to the recommended operating speed of the burr

An industrial quality general purpose 25 piece jobber drill set suitable for a wide range of steels and supplied in indexing metal case. Manufactured from High Speed Steel (HSS) with a black oxidised finish.

Features and Benefits
• High Speed Steel (HSS) ground flute drills for general purpose use
• Black oxide blue finish coating for bolstered longevity
• Convenient 25 piece metric set ranging from 1 to 13.00mm x 0.5mm to cover board range of uses
• Supplied in an indexed metal case for ease of storage

Contents
• 1mm x 0.5mm (1)
• 1.5mm x 0.5mm (1)
• 2mm x 0.5mm (1)
• 2.5mm x 0.5mm (1)
• 3mm x 0.5mm (1)
• 3.5mm x 0.5mm (1)
• 4mm x 0.5mm (1)
• 4.5mm x 0.5mm (1)
• 5mm x 0.5mm (1)
• 5.5mm x 0.5mm (1)
• 6mm x 0.5mm (1)
• 6.5mm x 0.5mm (1)
• 7mm x 0.5mm (1)
• 7.5mm x 0.5mm (1)
• 8mm x 0.5mm (1)
• 8.5mm x 0.5mm (1)
• 9mm x 0.5mm (1)
• 9.5mm x 0.5mm (1)
• 10mm x 0.5mm (1)
• 10.5mm x 0.5mm (1)
• 11mm x 0.5mm (1)
• 11.5mm x 0.5mm (1)
• 12mm x 0.5mm (1)
• 12.5mm x 0.5mm (1)
• 13mm x 0.5mm (1)

Typical Applications
• Steels
• Cast steel
• Grey cast iron
• Malleable cast iron
• Nickel brass
• Aluminium alloy
• Graphite

Standards
• BS328:Part 1
• DIN 338N
• ANSI B94 -11M

The J100 Series are general purpose HSS straight shank drills with a black oxide finish. Ideal for applications involving steel (including cast steel) cast iron (including malleable cast iron) as well as nickel, brass aluminium alloys and graphite. Their 118° point allows for precise hole alignment and reliable cutting performance whilst the black oxide coating helps reduce heat by retaining coolant on the tool surface. The coating also helps reduce the risk of the tool staining.

Features and Benefits
• High speed steel construction for increased tool durability
• Point angle of 118° for precise holemaking and precision cutting
• Black oxide coating helps aid chip flow, reduce heat and prevent staining
• Ideal for applications involving steel, iron, nickel, brass, aluminium alloy and graphite

Typical Applications
• Cutting and drilling
• Ferrous materials
• Steel
• Iron
• Nickel
• Brass
• Aluminium alloy
• Graphite

Notes
• Available in sizes 0.25mm -20.00mm

Standards
• Manufactured to BS 328/DIN338RN
